title: "CN2510-8"
category: "Industrial Communication > Network Servers for Serial Devices > Terminal Servers"
---

**Kategorie:** Industrial Communication > Network Servers for Serial Devices > Terminal Servers

# CN2510-8

Serial communication device, Serial: RS-232, Temp: 0 to 55°C (32 to 131°F), Power: 100 to 240 VAC (47 to 63 Hz)

**Dostupnost:** Not in stock (0 pcs)

## Základní informace

| Parametr | Hodnota |
| --- | --- |
| Unit | pcs |
| Code 1 | 180812021330 |
| Warranty | 60 |
| Warranty for companies | 60 |
| Brand | MOXA |

## Podrobný popis

Serial communication device – 8-port RS-232 Async Server, 100 to 240 VAC power inputEthernet Interface10/100BaseT(X) Ports (RJ45 connector): 1Ethernet Software FeaturesManagement: Device Search Utility (DSU) DHCP Client TCP/IP UDPMIB: MIB-IISecurity: RADIUSUnicast Routing: RIPV1/V2 Static RouteWindows Real COM Drivers: Windows 11, 10, 8.1, 8, 7, Vista, XP, ME, 98 and 95Windows Server 2022, 2019, 2016, 2012 R2, 2012, 2008 R2, 2008, 2003, 2000 and NTWindows Embedded CE 5.0 and 6.0, Windows XP EmbeddedLinux Real TTY Drivers: Kernel versions: 6.x, 5.x, 4.x, 3.x, 2.6.x and 2.4.xFixed TTY Drivers: macOS versions: 14, 13, 12, 11 and 10.1x SCO UNIX, SCO OpenServer, UnixWare 7, QNX 4.25, QNX 6, Solaris 10, FreeBSD, AIX 5.x, HP-UX 11i, Mac OS XVirtual Machine: VMWare ESXi (Windows 11 / 10)VMware Fusion (Windows on macOS 14, 13, 12, 11 and 10.1x)Parallels Desktop (Windows on macOS 14, 13, 12, 11 and 10.1x)Arm®-based Platform Support: Windows 11Linux Kernel 6.x, 5.x and 4.xmacOS 14, 13, 12 and 11Android API: Android 3.1.x and laterSerial InterfaceConnector: 8-pin RJ45No. of Ports: 8Serial Standards: RS-232Operation Modes: Terminal modeBaudrate: 50 bps to 921.6 kbpsData Bits: 5, 6, 7, 8Stop Bits: 1, 1.5, 2Parity: None, Even, Odd, Space, MarkFlow Control: None RTS/CTS XON/XOFFPower ParametersInput Current: 125 mA @ 110 VACInput Voltage: 100 to 240 VAC (47 to 63 Hz)Physical CharacteristicsHousing: MetalInstallation: 19-inch rack mountingDimensions: 440 x 198 x 45 mm (17.3 x 7.8 x 1.77 in)Weight: 2,680 g (5.91 lb)Environmental LimitsOperating Temperature: 0 to 55°C (32 to 131°F)Storage Temperature (package included): -20 to 70°C (-4 to 158°F)Ambient Relative Humidity: 5 to 95% (non-condensing)Standards and CertificationsEMC: EN 55032/24EMI: CISPR 32, FCC Part 15B Class AEMS: IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m IEC 61000-4-4 EFT: Power: 4 kV; Signal: 2 kV IEC 61000-4-5 Surge: Power: 2.5 kV; Signal: 1 kV IEC 61000-4-6 CS: 150 kHz to 80 MHz: 3 V/m; Signal: 3 V/m IEC 61000-4-8 PFMF IEC 61000-4-11Safety: EN 60950-1 UL 60950-1MTBFTime: 857,279 hrsStandards: Telcordia (Bellcore) Standard TR/SRWarrantyWarranty Period: 5 yearsDetails: See www.moxa.com/warranty

## Soubory ke stažení

* [Manual CN2510_Users_Manual_v4_ELVAC15](https://www.elvac.eu/files/shop/moxa/manual/CN2510_Users_Manual_v4_ELVAC15.pdf)
* [Katalog CN2510_Series_ELVAC15](https://www.elvac.eu/files/shop/moxa/datasheet/CN2510_Series_ELVAC15.pdf)
