--- title: "EDS-316-M-SC-T" category: "Industrial Communication > Industrial Ethernet > Unmanaged Ethernet Switches" --- **Kategorie:** Industrial Communication > Industrial Ethernet > Unmanaged Ethernet Switches # EDS-316-M-SC-T Industrial Unmanaged Ethernet switch, Ports: 15 Auto negotiation speed Full/Half duplex mode Auto MDI/MDI-X connection, Temp: -40 to 75°C (-40 to 167°F) **Dostupnost:** Not in stock (0 pcs) ## Základní informace | Parametr | Hodnota | | --- | --- | | Unit | pcs | | Code 1 | 180412110949 | | Warranty | 60 | | Warranty for companies | 60 | | Brand | MOXA | ## Podrobný popis Industrial Unmanaged Ethernet switch – Unmanaged Ethernet switch with 15 10/100BaseT(X) ports, 1 100BaseFX multi-mode port with SC connector, relay output warning, -40 to 75°C operating temperatureInput/Output InterfaceAlarm Contact Channels: 1 relay output with current carrying capacity of 1 A @ 24 VDCEthernet Interface10/100BaseT(X) Ports (RJ45 connector): 15 Auto negotiation speed Full/Half duplex mode Auto MDI/MDI-X connection100BaseFX Ports (multi-mode SC connector): 1Standards: IEEE 802.3 for 10BaseT IEEE 802.3u for 100BaseT(X) and 100BaseFX IEEE 802.3x for flow controlOptical Fiber: Read more 100BaseFX Multi-Mode Single-Mode (40 km) Single-Mode (80 km) Fiber Cable Type OM1 50/125 µm G.652 G.652 800 MHz x km Typical Distance 4 km 5 km 40 km 80 km Wavelength Typical (nm) 1300 1310 1550 TX Range (nm) 1260 to 1360 1280 to 1340 1530 to 1570 RX Range (nm) 1100 to 1600 1100 to 1600 1100 to 1600 Optical Power TX Range (dBm) -10 to -20 0 to -5 0 to -5 RX Range (dBm) -3 to -32 -3 to -34 -3 to -34 Link Budget (dB) 12 29 29 Dispersion Penalty (dB) 3 1 1 Note: When connecting a single-mode fiber transceiver, we recommend using an attenuator to prevent damage caused by excessive optical power.Note: Compute the “typical distance” of a specific fiber transceiver as follows: Link budget (dB) > dispersion penalty (dB) + total link loss (dB).DIP Switch ConfigurationEthernet Interface: Port break alarmSwitch PropertiesPacket Buffer Size: 1.25 MbitsMAC Table Size: 4 KProcessing Type: Store and ForwardPower ParametersInput Voltage: 12/24/48 VDC Redundant dual inputsInput Current: 0.35 A @ 24 VDCConnection: 1 removable 6-contact terminal block(s)Operating Voltage: 9.6 to 60 VDCReverse Polarity Protection: SupportedOverload Current Protection: SupportedPhysical CharacteristicsHousing: MetalIP Rating: IP30Dimensions: 80.1 x 135 x 105 mm (3.15 x 5.31 x 4.13 in)Weight: 1140 g (2.52 lb)Installation: DIN-rail mounting Wall mounting (with optional kit)Environmental LimitsOperating Temperature: -40 to 75°C (-40 to 167°F)Storage Temperature (package included): -40 to 85°C (-40 to 185°F)Ambient Relative Humidity: 5 to 95% (non-condensing)Standards and CertificationsSafety: EN 62368-1 UL 508 UL 60950-1 CSA C22.2 No. 60950-1EMC: EN 55032/35EMI: CISPR 32, FCC Part 15B Class AEMS: IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV IEC 61000-4-3 RS: 80 MHz to 1 MHz: 20 V/m IEC 61000-4-4 EFT: Power: 2 kV; Signal: 1 kV IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV IEC 61000-4-6 CS: 10 V IEC 61000-4-8 PFMFHazardous Locations: ATEX Class I Division 2Vibration: IEC 60068-2-6Shock: IEC 60068-2-27Freefall: IEC 60068-2-32Maritime: DNVMTBFTime: 2,048,802 hrsStandards: MIL-HDBK-217FWarrantyWarranty Period: 5 yearsDetails: See www.moxa ## Technická specifikace | Vlastnost | Hodnota | | --- | --- | | Min. provozní teplota | Min. provozní teplota -40 °C | | Max. provozní teplota | Max. provozní teplota 75 °C | | Celkový počet LAN portů | Celkový počet LAN portů 16 | | Počet metalických LAN portů | Počet metalických LAN portů 15 | | Počet optických LAN portů | Počet optických LAN portů 1 | | Počet portů max 100 Mb | Počet portů max 100 Mb 16 | | Normy | Normy ATEX Zone 2; DNV / GL; UL 508 / UL 60950-1 | ## Soubory ke stažení * [Manual EDS-316_HIG_4e_ELVAC15](https://www.elvac.eu/files/shop/moxa/manual/EDS-316_HIG_4e_ELVAC15.pdf) * [Katalog EDS-305_308_309_316_Series_ELVAC15](https://www.elvac.eu/files/shop/moxa/datasheet/EDS-305_308_309_316_Series_ELVAC15.pdf)
