# ioLogik 2542-T

Serial converter, Serial: RS-232 RS-422 RS-485, LAN: PWR, RDY, Serial port (P1, P2), Ethernet port (L1 to L4),, Protocols: CGI commands Modbus TCP Client (Master) Modbus TCP Server, Temp: -40 to

**Dostupnost:** Not in stock (0 pcs)

## Základní informace

| Parametr | Hodnota |
| --- | --- |
| Unit | pcs |
| Code 1 | 200412025085 |
| Warranty | 60 |
| Warranty for companies | 60 |
| Brand | MOXA |

## Podrobný popis

Serial converter – Universal controller, 4 AIs, 12 DIOs, Click&Go Plus, -40 to 75°C operating temperatureMemorymicroSD Slot: Up to 32 GB (SD 2.0 compatible) Note: For units operating in extreme temperatures, industrial-grade, wide-temperature microSD cards are required.Control LogicLanguage: Click&Go PlusInput/Output InterfaceConfigurable DIO Channels (by software): 12Analog Input Channels: 4Buttons: Reset buttonIsolation: 3k VDC or 2k VrmsDigital InputsConnector: Screw-fastened Euroblock terminalSensor Type: Dry contact Wet contact (NPN or PNP)I/O Mode: DI or event counterDry Contact: On: short to GND Off: openWet Contact (DI to COM): On: 10 to 30 VDC Off: 0 to 3 VDCCounter Frequency: 2.5 kHzDigital Filtering Time Interval: Software configurablePoints per COM: 6 channelsDigital OutputsConnector: Screw-fastened Euroblock terminalI/O Type: SinkI/O Mode: DO or pulse outputCurrent Rating: 500 mA per channelPulse Output Frequency: 5 kHz (max.)DIO Output Leakage Current: < 1 mA @ 30 VDCOvercurrent Protection: 1.5 A per channel @ 25°COver-temperature Shutdown: 175°C (typical), 150°C (min.)Over-voltage Protection: 45 VDC (typical)Analog InputsConnector: Screw-fastened Euroblock terminalI/O Mode: Voltage/CurrentI/O Type: DifferentialConverter Resolution: 16 bitsInput Range: ±10 VDC 0 to 10 VDC 0 to 20 mA 4 to 20 mA 4 to 20 mA (with burn-out detection)Accuracy: ±0.1% FSR @ 25°C ±0.3% FSR @ -10 to 60°C ±0.5% FSR @ -40 to 75°CSampling Rate: All channels: 400 samples/sec Per channel: 100 samples/secBuilt-in Resistor for Current Input: 120 ohmsInput Impedance: 1 mega-ohms (min.)Over-Voltage Protection: -25 to +30 VDC (power on) -35 to +35 VDC (power off)Ethernet Interface10/100BaseT(X) Ports (RJ45 connector): 4, 1 MAC addressMagnetic Isolation Protection: 1.5 kV (built-in)Ethernet Software FeaturesConfiguration Options: Web Console (HTTP/HTTPS) Windows Utility (IOxpress)Industrial Protocols: CGI commands Modbus TCP Client (Master) Modbus TCP Server (Slave) Moxa AOPC (Active Tag) MXIO Library RESTful API SNMPv1/v2c/v3 SNMPv1/v2c TrapManagement: BOOTP, IPv4, SMTP, TCP/IP, DHCP ClientMIB: Device Settings MIBSecurity: HTTPS/SSLTime Management: SNTPLED InterfaceLED Indicators: PWR, RDY, Serial port (P1, P2), Ethernet port (L1 to L4), I/O Channel Status (0 to 15)Serial InterfaceBaudrate: 300, 1200, 1800, 2400, 4800, 7200, 9600, 19200, 38400, 57600, 115200 bpsConnector: 8-pin RJ45Data Bits: 5, 6, 7, 8Flow Control: None RTS/CTS XON/XOFFNo. of Ports: 2Parity: None

## Technická specifikace

| Vlastnost | Hodnota |
| --- | --- |
| Min. provozní teplota | Min. provozní teplota
-40 °C |
| Max. provozní teplota | Max. provozní teplota
75 °C |
| Počet analogových vstupů | Počet analogových vstupů
4 |
| Počet digitálních vstupů/výstupů | Počet digitálních vstupů/výstupů
12 |
| Počet portů LAN | Počet portů LAN
4 |
| Interní logika | Interní logika
Ne |

## Soubory ke stažení

* [Katalog ioLogik_2500_Series_ELVAC15](https://www.elvac.eu/files/shop/moxa/datasheet/ioLogik_2500_Series_ELVAC15.pdf)
* [Manual ioLogik_2500_Users_Manual_v2_ELVAC15](https://www.elvac.eu/files/shop/moxa/manual/ioLogik_2500_Users_Manual_v2_ELVAC15.pdf)
