# ioLogik E1512-M12-T

I/O module, LAN: PWR, RDY, EXP, LAN, DI channels, DO channels, Protocols: Modbus TCP Server (Slave) Moxa AOPC (Active Tag) MXIO Lib, Temp: -40 to 85°C (-40 to 185°F), Power: 1

**Dostupnost:** Not in stock (0 pcs)

## Základní informace

| Parametr | Hodnota |
| --- | --- |
| Unit | pcs |
| Code 1 | 200412026390 |
| Warranty | 60 |
| Warranty for companies | 60 |
| Brand | MOXA |

## Podrobný popis

I/O module – Rugged I/O, 4 DIs, 4 DIOs, -40 to 85°C operating temperatureInput/Output InterfaceDigital Input Channels: 4Configurable DIO Channels (by software): 4Isolation: 3k VDC or 2k VrmsButtons: Reset buttonDigital InputsConnector: Spring-type Euroblock terminalCounter Frequency: 250 HzDigital Filtering Time Interval: Software configurableDry Contact: On: short to GND Off: openI/O Mode: DI or event counterPoints per COM: 2 channelsSensor Type: Dry contact Wet contact (NPN or PNP)Wet Contact (DI to GND): On: 10 to 30 VDC Off: 0 to 3 VDCDigital OutputsConnector: Spring-type Euroblock terminalCurrent Rating: 200 mA per channelI/O Mode: DO or pulse outputI/O Type: SinkOver-Current Protection: 0.65 A per channel @ 25°COver-Temperature Shutdown: 175°C (typical), 150°C (min.)Over-Voltage Protection: 35 VDCPulse Output Frequency: 500 HzEthernet Interface10/100BaseT(X) Ports (M12 D-coded 4-pin female connector): 1Magnetic Isolation Protection: 1.5 kV (built-in)Ethernet Software FeaturesConfiguration Options: Web Console (HTTP) Windows Utility (ioSearch)Industrial Protocols: Modbus TCP Server (Slave) Moxa AOPC (Active Tag) MXIO LibraryManagement: BOOTP DHCP Client HTTP IPv4 TCP/IP UDPLED InterfaceLED Indicators: PWR, RDY, EXP, LAN, DI channels, DO channelsModbus TCPMode: Server (Slave)Functions Supported: 1, 2, 3, 4, 5, 6, 15, 16Power ParametersPower Connector: Spring-type Euroblock terminalNo. of Power Inputs: 1Input Voltage: 12 to 48 VDCPower Consumption: 150 mA @ 24 VDCPhysical CharacteristicsHousing: AluminumDimensions: 144 x 124 x 30 mm (5.67 x 4.88 x 1.18 in)Weight: 825 g (1.82 lb)Installation: DIN-rail mounting Wall mounting (with optional kit)Wiring: I/O cable, 16 to 26 AWG Power cable, 16 to 26 AWGEnvironmental LimitsOperating Temperature: -40 to 85°C (-40 to 185°F)Storage Temperature: -40 to 85°C (-40 to 185°F)Ambient Relative Humidity: 5 to 95% (non-condensing)Altitude: 2000 m Please contact Moxa if you require products guaranteed to function properly at higher altitudes.Standards and CertificationsEMC: EN 61000-6-2/-6-4EMI: CISPR 32, FCC Part 15B Class AEMS: IEC 61000-4-2 ESD: Contact: 8 kV; Air: 15 kV IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m IEC 61000-4-4 EFT: Power: 2 kV; Signal: 2 kV IEC 61000-4-5 Surge: Power: 2 kV; Signal: 2 kV IEC 61000-4-6 CS: 10 V IEC 61000-4-8 PFMFRailway: EN 50121-4 EN 50155Safety: UL 508Shock: IEC 60068-2-27Vibration: IEC 60068-2-6DeclarationGreen Product:

## Technická specifikace

| Vlastnost | Hodnota |
| --- | --- |
| Min. provozní teplota | Min. provozní teplota
-40 °C |
| Max. provozní teplota | Max. provozní teplota
85 °C |
| Počet digitálních vstupů | Počet digitálních vstupů
4 |
| Počet digitálních vstupů/výstupů | Počet digitálních vstupů/výstupů
4 |
| Počet portů LAN | Počet portů LAN
1 |

## Soubory ke stažení

* [Katalog ioLogik_E1500_Series_ELVAC15](https://www.elvac.eu/files/shop/moxa/datasheet/ioLogik_E1500_Series_ELVAC15.pdf)
* [Manual ioLogik_E1500_Series_Users_Manual_v4_ELVAC15](https://www.elvac.eu/files/shop/moxa/manual/ioLogik_E1500_Series_Users_Manual_v4_ELVAC15.pdf)
