# SPL-24

Power supply, Dimensions: 24.9 x 100 x 86.2 mm (0.98 x 3.93 x 3.39 in)

**Dostupnost:** Not in stock (0 pcs)

## Základní informace

| Parametr | Hodnota |
| --- | --- |
| Unit | pcs |
| Code 1 | 180424113510 |
| Warranty | 60 |
| Warranty for companies | 60 |
| Brand | MOXA |

## Podrobný popis

Power supply – PoE splitter with maximum output of 12.95 W at 24 VDC, 0 to 60°C operating temperatureEthernet Interface10/100BaseT(X) Ports (RJ45 connector): 1 Full/Half duplex mode Auto MDI/MDI-X connection Auto negotiation speedPoE Ports (PD), 10/100BaseT(X), RJ45 Connector: 1 Full/Half duplex mode Auto MDI/MDI-X connection Auto negotiation speedStandards: IEEE 802.3af for PoE IEEE 802.3 for 10BaseT IEEE 802.3u for 100BaseT(X)Power ParametersOperating Voltage: 44 to 75 VDC (PoE)Overload Current Protection: SupportedOutput Voltage Rating: 24 VDCOutput Power Rating: 12.95 W (max.)Connection: 1 removable 3-contact terminal block(s)Physical CharacteristicsDimensions: 24.9 x 100 x 86.2 mm (0.98 x 3.93 x 3.39 in)Installation: DIN-rail mountingIP Rating: IP30Weight: 95 g (0.21 lb)Environmental LimitsOperating Temperature: 0 to 60°C (32 to 140°F)Storage Temperature (package included): -40 to 85°C (-40 to 185°F)Ambient Relative Humidity: 5 to 95% (non-condensing)Standards and CertificationsSafety: UL 60950-1EMC: EN 55032/24EMI: CISPR 32, FCC Part 15B Class AEMS: IEC 61000-4-2 ESD: Contact: 6 kV; Air: 8 kV IEC 61000-4-3 RS: 80 MHz to 1 GHz: 10 V/m IEC 61000-4-4 EFT: Signal: 2 kV IEC 61000-4-5 Surge: Signal: 1 kV IEC 61000-4-6 CS: 10 V IEC 61000-4-8 PFMFFreefall: IEC 60068-2-31Shock: IEC 60068-2-27Maritime: DNV-GL, ABS, LR, NKVibration: IEC 60068-2-6MTBFTime: 5,104,703 hrsStandards: MIL-HDBK-217FWarrantyWarranty Period: 5 yearsDetails: See www.moxa.com/warranty

## Soubory ke stažení

* [Katalog SPL-24_Series_ELVAC15](https://www.elvac.eu/files/shop/moxa/datasheet/SPL-24_Series_ELVAC15.pdf)
* [Manual EDS-P308_SPL-24_HIG_4e_ELVAC15](https://www.elvac.eu/files/shop/moxa/manual/EDS-P308_SPL-24_HIG_4e_ELVAC15.pdf)
