# UC-2102-LX

Industrial embedded computer, CPU: Armv7 Cortex-A8 600 MHz, RAM: 256 MB DDR3, Storage: 8 GB eMMC, LAN: 2 per port (10/100 Mbps), OS: Moxa Industrial Linux 1 (Debian 9, kernel 4.4), 2027 EOLS, Temp

**Dostupnost:** Not in stock (0 pcs)

## Základní informace

| Parametr | Hodnota |
| --- | --- |
| Unit | pcs |
| Code 1 | 182008121515 |
| Warranty | 60 |
| Warranty for companies | 60 |
| Brand | MOXA |

## Podrobný popis

Industrial embedded computer – Mini RISC-based embedded computer with 600 MHz processor and 2 LAN portsComputerCPU: Armv7 Cortex-A8 600 MHzDRAM: 256 MB DDR3Storage Pre-installed: 8 GB eMMCSupported OS: Moxa Industrial Linux 1 (Debian 9, kernel 4.4), 2027 EOLSee www.moxa.com/MILComputer InterfaceEthernet Ports: Auto-sensing 10/100 Mbps ports (RJ45 connector) x 2Console Port: RS-232 (TxD, RxD, GND), 4-pin header output (115200, n, 8, 1)Buttons: Reset button DIP switch for serial port configurationEthernet InterfaceMagnetic Isolation Protection: 1.5 kV (built-in)Serial InterfaceBaudrate: 50 bps to 921.6 kbpsData Bits: 5, 6, 7, 8Stop Bits: 1, 1.5, 2Parity: None, Even, Odd, Space, MarkFlow Control: RTS/CTS, XON/XOFF ADDC (automatic data direction control) for RS-485 RTS Toggle (RS-232 only)Pull High/Low Resistor for RS-485: 1 kilo-ohm, 150 kilo-ohmsESD Protection: 4 kV, for all signalsSerial SignalsRS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GNDRS-422: Tx+, Tx-, Rx+, Rx-, GNDRS-485-2w: Data+, Data-, GNDLED IndicatorsSystem: Power x 1LAN: 2 per port (10/100 Mbps)User Programmable: User x 2Physical CharacteristicsHousing: MetalDimensions (with ears): 73 x 80 x 28 mm (2.87 x 3.15 x 1.10 in)Dimensions (without ears): 50 x 80 x 28 mm (1.97 x 3.15 x 1.10 in)Weight: 190 g (0.42 lb)Installation: Wall mounting DIN-rail mounting (with optional kit)Environmental LimitsOperating Temperature: -10 to 60°C (14 to 140°F)Storage Temperature: -20 to 70°C (-4 to 158°F)Ambient Relative Humidity: 5 to 95% (non-condensing)Shock: IEC 60068-2-27Vibration: 2 Grms @ IEC 60068-2-64, random wave, 5-500 Hz, 1 hr per axis (without USB devices attached)Power ParametersInput Voltage: 9 to 48 VDCInput Current: 0.45 A @ 9 VDC, 0.084 A @ 48 VDCPower Consumption: 4 WMTBFTime: 1,652,339 hrsStandards: Telcordia (Bellcore) Standard TR/SRReliabilityAlert Tools: External RTC (real-time clock)Automatic Reboot Trigger: External WDT (watchdog timer)Standards and CertificationsEMC: EN 55032/35 UKCA, VCCI, BISEMI: FCC Part 15B Class A ICES-003 Class A EN 55032 Class A EN 61000-6-4 Class AEMS: IEC 61000-4-2 ESD: Contact: 4 kV; Air: 8 kV IEC 61000-4-3 RS: 80 MHz to 1 GHz: 3 V/m IEC 61000-4-4 EFT: Power: 1 kV; Signal: 0.5 kV IEC 61000-4-5 Surge: Power: 0.5 kV; Signal: 1 kV IEC 61000-4-6 CS: 3 V IEC 61000-4-8 PFMFSafety: IEC 60950-1 UL 60950-1International Approval: FCC, CE, UKCA, VCCI BISGreen Product: RoHS, CRoHS, WEEEWarrantyWarranty Period: 5

## Soubory ke stažení

* [Katalog](https://www.elvac.eu/ipc/download/moxa/datasheet/uc-2100-series-datasheet-v3.0_2024.pdf)
