V2403C-LTECat4-EU

Industrial embedded computer – Telit LE910C4 LTE Cat. 4 mini card for Europe, 3 SMA antenna cables

Computer

• Storage Slot: 2.5-inch HDD/SSD slots x 2 mSATA slots x 1
• Supported OS: Windows 10 Embedded IoT Ent 2019 LTSC 64-bitWindows 10 Embedded IoT Ent 2021 LTSC 64-bitLinux Debian 9 imageLinux Debian 11/Ubuntu 20.04/CentOS 7.9 drivers
• System Memory Slot: SODIMM DDR4 slot x 2
• DRAM: 32 GB max

Computer Interface

• Ethernet Ports: Auto-sensing 10/100/1000 Mbps ports (RJ45 connector) x 4
• Serial Ports: RS-232/422/485 ports x 4, software selectable (DB9 male)
• Digital Output: DOs x 4
• Digital Input: DIs x 4
• USB 3.0: USB 3.0 hosts x 4, type-A connectors
• Audio Input/Output: Line in x 1, Line out x 1, 3.5 mm phone jack
• Video Output: HDMI x 1, HDMI connector (standard) DP x 1, DisplayPort connector (standard)
• Wi-Fi Antenna Connector: RP-SMA x 3
• Cellular Antenna Connector: SMA x 2 (optional)
• GPS Antenna Connector: SMA x 1 (optional)
• Expansion Slots: mPCIe slots x 2
• SIM Format: Micro
• Number of SIMs: 4

Digital Inputs

• Connector: Screw-fastened Euroblock terminal
• I/O Mode: DI
• Isolation: 3k VDC
• Sensor Type: Wet contact (NPN or PNP) Dry contact
• Dry Contact: Logic 0: Short to GND Logic 1: Open
• Wet Contact (DI to COM): Logic 0: 0 to 3 VDC Logic 1: 10 to 30 VDC

Digital Outputs

• Connector: Screw-fastened Euroblock terminal
• Current Rating: 200 mA per channel
• I/O Type: Sink
• Voltage: 0 to 30 VDC
• Isolation: 3k VDC

LED Indicators

• System: Power x 1 Storage x 1
• LAN: 2 per port (10/100/1000 Mbps)
• Serial: 2 per port (Tx, Rx)

Serial Interface

• Baudrate: 50 bps to 115.2 kbps
• Connector: DB9 male
• ESD: Contact: 6 kV; Air: 8 kV (level 3)
• Isolation: 2 kV
• Data Bits: 5, 6, 7, 8
• Flow Control: RTS/CTS, XON/XOFF, ADDC® (automatic data direction control) for RS-485, RTS Toggle (RS-232 only)
• Parity: None, Even, Odd, Space, Mark
• Stop Bits: 1, 1.5, 2

Serial Signals

• RS-232: TxD, RxD, RTS, CTS, DTR, DSR, DCD, GND
• RS-422: Tx+, Tx-, Rx+, Rx-, GND
• RS-485-2w: Data+, Data-, GND
• RS-485-4w: Tx+, Tx-, Rx+, Rx-, GND

Power Parameters

• Input Voltage: 12 to 48 VDC
• Power Connector: Terminal block
• Power Consumption (Max.): 70 W (max.)

Power Ignition Control

• Switch Type: Rotary (front panel)
• Switch Settings: Setting 0: IGT function disabledSetting 1: PWR ON delay: 0.5 sec; PWR OFF delay: 30 secSetting 2: PWR ON delay: 1 sec; PWR OFF delay: 30 secSetting 3: PWR ON delay: 1 sec; PWR OFF delay: 60 secSetting 4: PWR ON delay: 2 sec; PWR OFF delay: 60 secSetting 5: PWR ON delay: 2 sec; PWR OFF delay: 90 secSetting 6: PWR ON delay: 3 sec; PWR OFF delay: 90 secSetting 7: PWR ON delay: 3 sec; PWR OFF delay: 15
